I'd like to introduce dsmq, the Dead Simple Message Queue, to the world.
Part mail room, part bulletin board, dsmq is a central location for sharing messages between processes, even when they are running on different computers.
Its defining characteristic is bare-bones simplicity.
What dsmq does
A message queue lets different processes talk to each other, within or across machines. Message queues are a waystation, a place to publish messages and hold them until they get picked up by the process that needs them.
In dsmq, a program running the message queue starts up first (the server). It handles all the receiving, delivering, sorting, and storing of messages.
Other programs (the clients) connect to the server. They add messages to a queue or read messages from a queue. Each queue is a separate topic.
Why message queues?
Message queues are invaluable for distributed systems of all sorts, but my favorite application is robotics. Robots typically have several (or many) processes doing different things at different speeds. Communication between processes is a fundamental part of any moderately complex automated system. When ROS (the Robot Operating System) was released, one of the big gifts it gave to robot builders was a reliable way to pass messages.
Why another message queue?
There are lots of message queues in the world, and some are quite well known—Amazon SQS, RabbitMQ, Apache Kafka to name a few. It's fair to ask why this one was created.
The official reason for dsmq's existence is that all the other available options are pretty heavy. Take RabbitMQ for instance, a popular open source message queue. It has hundreds of associated repositories and it's core rabbitmq-server repo has many thousands of lines of code. It's a heavy lift to import this to support a small robotics project, and code running on small edge devices may struggle to run it at all.
RabbitMQ is also mature and optimized and dockerized and multi-platform and fully featured and a lot of other things a robot doesn't need. It would be out of balance to use it for a small project.
dsmq is only about 200 lines of Python, including client and server code. It's tiny. Good for reading and understanding front-to-back when you're integrating it with your project.
But the real reason is that I wanted to understand how a message queue might work and the best way I know to learn this is to build one.
How to use dsmq
Install it
pip install dsmq
or
uv add dsmq
Spin up a dsmq server
from dsmq import dsmq
dsmq.start_server(host="127.0.0.1", port=12345)
Connect a client to a dsmq server
mq = dsmq.connect_to_server(host="127.0.0.1", port=12345)
Add a message to a topic queue
topic = "greetings"
msg = "hello world!"
mq.put(topic, msg)
Read a message from a topic queue
topic = "greetings"
msg = mq.get(topic)
Run a demo
- Open 3 separate terminal windows.
- In the first, run
src/dsmq/dsmq.py
. - In the second, run
src/dsmq/example_put_client.py
. - In the third, run
src/dsmq/example_get_client.py
.
Alternatively, if you're on Linux just run src/dsmq/demo_linux.py
. (Linux has some process forking capabilities that Windows doesn't and that macOS forbids. It makes for a nice self-contained multiprocess demo.)
How it works
- ▪ Many clients can read messages from the same topic queue. dsmq uses a one-to-many publication model.
- ▪ A client will get the oldest message available on a requested topic. Queues are first-in-first-out.
- ▪ Clients will only be able to get messages that were added to a queue after the time they connected to the server. Any messages older that that won't be visible.
- ▪ dsmq is asyncronous. There are no guarantees about how soon a message will arrive at its intended client.
- ▪ dsmq is backed by an in-memory SQLite database. If your message volumes get larger than your RAM, you will reach an out-of-memory condition.
sqlite_conn = sqlite3.connect("file:mem1?mode=memory&cache=shared")
- ▪
put()
andget()
operations are fairly quick—less than 100 μs of processing time plus any network latency—so it can comfortably handle requests at rates of hundreds of times per second. But if you have several clients reading and writing at 1 kHz or more, you may overload the queue. - ▪ A client will not be able to read any of the messages that were put into a queue before it connected.
- ▪ Messages older than 600 seconds will be deleted from the queue.
- ▪ In case of contention for the lock on the database, failed queries will be retried several times, with exponential backoff. None of this is visible to the clients, but it helps keep the internal operations reliable.
for i_retry in range(_n_retries):
try:
cursor.execute("""...
- ▪ To keep things bare bones, the connections are all implemented in the socket layer, rather than WebSockets or http in the application layer.
self.dsmq_conn = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
self.dsmq_conn.connect((host, port))
- ▪ ...however, working on this lower level meant dsmq had to reinvent the wheel of message headers. Each dsmq message is sent with a header that tells it exactly how many bytes to expect in it. The header format is simplistic—a message with one million plus the number of byes in the following message. Doing it this way means that the header is exactly 23 bytes long every time. (As long as the message is less than nine million bytes.)
- ▪ Every time a new client connects to the server, a new thread is created. That thread listens for any
get()
orput()
requests the client might make and handles them immediately.
Thread(target=_handle_client_connection, args=(socket_conn,)).start()
- ▪ dsmq retrieves the oldest eligible message from the queue. If a client wants to ensure it is getting the most recent message from the queue, it will need to iteratively get messages until there are no more left to be gotten.
msg_str = "<no response>"
response = None
while response != "":
msg_str = response
response = self.mq.get("<topic>")
- ▪ dsmq messages are text fields, but Python dictionaries are a very convenient and common format for passing structured messages. Use the
json
library to convert from dictionaries to strings and back.
topic = "update"
msg_dict = {"timestep": 374, "value": 3.897}
msg_str = json.dumps(msg_dict)
dsmq.put(topic, msg_str)
msg_str = dsmq.get(topic)
msg_dict = json.loads(msg_str)
- ▪ dsmq is opinionated. Parameters for controlling behavior are set to reasonable defaults and not exposed to the user. The additional complexity in the API is not worth the value of making them user-controlled. However they are also clearly labeled and very easy to find. If anyone cares enough to play with them, they are strongly encouraged to fork dsmq and make it their own.
_message_length_offset = 1_000_000
_header_length = 23
_n_retries = 5
_first_retry = 0.01 # seconds
_time_to_live = 600.0 # seconds
- ▪ dsmq is deliberately built to have as few dependencies as it can get away with. As of this writing, it doesn't depend on any third party packages and just a handful of core packages:
json
,socket
,sqlite3
,sys
, andthreading
.
Dead Simple
Dead simple is an aesthetic. It says that the ideal is achieved not when nothing more can be added, but when nothing more can be taken away. It is the aims to follow the apocryphal advice of Albert Einstein, to make a thing as simple as possible, but no simpler.
Dead simple is like keystroke golfing, but instead of minimizing the number of characters, it minimizes the number of concepts a developer or a user has to hold in their head.
I've tried to embody it in dsmq. dsmq has fewer lines of code than RabbitMQ has repositories. And that tickles me.
